6.6 Programming of the overfill protection (DLT3)
The overfill level cannot be below the level of the return value!
The return value cannot be above the overfill level!
Activate the programming menu by pressing „OK“. Switch to main menu 2. via the buttons „▲“
or „▼“ and press button „OK“ 2 times. You have reached menu item 2.1.. Enter password (123)
as per chap. 6.4.
Switch to menu item “Activation Overfill protection” (2.6.) via the buttons „▲“ or „▼“ and press
„OK“.
Change the value „0 0 0.” to „0 0 1.” (buttons „▲“ or „▼“) and press „OK“.
Choose menu item “Overfill limit level (%) / LIMIT” (2.8.) via the buttons „▲“ or „▼“ and press
„OK“.
Display: → 0X.XX (The grey area is the viewable area of the display / X means a value of
0-9)
The buttons „▲“ (value of return level) or „▼“ (100%) are a quick way to set the starting point
for the LIMIT. After pressing „OK“ the display is 0XX.X .
Enter the desired LIMIT value e.g. „075” for 75% and press „OK“. You reach the last digit via
„OK“.
Choose menu item „return level (%)“ (2.7.) via the buttons „▲“ or „▼“ and press „OK“.
Display: → 0X.XX (The grey area is the viewable area of the display / X means a value of
0-9)
The buttons „▲“ (0%) or „▼“ (value of overfill limit) are a quick way to set the starting point for
the return level. After pressing „OK“ the display is 0XX.X .
Enter the desired return level e.g. „070” for 70% and press „OK“. You reach the last digit via
„OK“.
The return level is the value at which the DLT3 return to normal operation
and thus the output relay returns into the normal operation mode (relay
contacts 3 and 5 closed).
