7. Technical Data
7.1 Device data
Manufacture in accordance with: EU-Directive 2014/68/EU
applied standards: EN 13445-1, EN 61326-1, EN 61010-1
EN 12952-11, EN 12953- 9
Other Technical Regulations: Water level 100 - dated February 2010
Supply voltage: 230V AC (-15% +10%), 50/60Hz
Power consumption: 3VA
Data exchange: digital measurement value output
Electrical connection: 12-pole Screw terminal strip
Protection class: IP40 in accordance with DIN EN 60529
(protection class IP54 is to be ensured in the boiler area)
Device fuse: 63 mA/T
Allowable ambient temperature: 0°C bis 55°C
Supply voltage probe: short-circuit-proof, 24V / 2W
Self-test alle 3sec
Service life probe: The service life of the probe depends on the operating
conditions and state of the boiler water.
The total length of lead: max. 250m
7.2 Maximum ratings of outputs
