MOUNTING ON THE WALL
Before mounting please ensure the wall is suitable for this
type of appliance.
a b
14.9cm
30cm min.
100cm min.
24.8cm
10cm min.
• Find the correct position on the wall. There must be a minimum clearance of
10cm between the oor and the base of the appliance once in position.
• Using an electrical drill, drill 2 holes (a,b) on the wall. The distance between
holes a and b should be 14.9cm. the depth of the hole should be about 4cm
• Fix the screws and bracket onto the wall, please pay attention to the position
of the bracket and if any hazards are within range.
• Line up the holes of the bracket to the back of the appliance and let the clip
hold the appliance. Screw the appliance to the bracket through the aligned
holes.
