Remote Control
1 On/off button
2 Power setting button
3 Temperature control button
4 Timer control button
5 Child lock function button
ASSEMBLY INSTRUCTIONS
Before assembly: Take the heater out of the box and
remove all packaging material. Check the installation parts
are not damaged and nothing is missing.
• In order to use the heater, it must be either wall
mounted or assembled onto the castors and wheels.
Feet Assembly
Turn the appliance upside down. Attach the two feet onto
the bottom of the appliance and x with the four small
screws provided for each side. Ensure the feet are aligned
so that the angle matches the angle of the heater and
therefore the feet will lie at on the oor (see g. 1). Insert
the four small wheels into the two feet.
Fig. 1
