iGenix IG9750 - Technical Specification; Assembly Instructions; Installation of the Water Tank; Foot-Wheel Installation

5
1
2
3
Water Tank Fastener
Water Tank
Ice Box
Take out the
water tank
cover from the
fan body
Fix the cover
on the water
tank
Wheel
Control Panel
Air Outlet
Water Window
TECHNICAL SPECIFICATION
ASSEMBLY INSTRUCTIONS
Model IG9750
Supply Voltage: 220-240V, 50Hz
Max Output: 200W
Max Airow Volume: 798m³/h
Water tank: 50 Litres
Net Weight: 15.3kg
Installation of the Water Tank:
Foot-Wheel Installation:
Front Foot-Wheel
Rear Foot-Wheel
