Igloo JSCRP - Technical Data; Figure 1 JSCRP and J2 SCRP; Table 1 Technical Data

REFRIGERATION LTD
4
www.igloorefrigeration.com | Pastry Cases
1 – Stainless steel upper shelf
2 – Evaporator coil
3 – Rail (condensate outflow after defrosting the
evaporator)
4 – Sliding door
5 – Inner frame
6 – Compressor
7 – LED lamp
8 – Cured front glass
9 – Base of the unit (DO NOT BLOCK air louver!!!)
10 – ABS sides
11 – Control panel
12 – Condenser cover (DO NOT BLOCK air louver!!!)
13 – Leveling legs
14 – Serial plate
15 – Straight front glass
2.3. Technical data
Table 1 Technical data
Model
Voltage
[V/Hz/Ph]
Rated Current
[A]
Max shelf load
[lbs/kg]
Weight
[lbs/kg]
JSCRP4/J2SCRP4
115/60/1
8 (max.fuse:15)
66/30
337/153
JSCRP6/J2SCRP6
115/60/1
8 (max.fuse:15)
66/30
529/240
JSCRP8//J2SCRP8
115/60/1
15 (max.fuse:20)
66/30
661/300
Figure 1 JSCRP and J2SCRP
J2SCRP (Straight glass)
JSCRP (Cured glass)
