1. UNLOADING
The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.
2. PROPERTIES OF THE DEVICE
2.1. Purpose
SAMOS is a universal cooling device used to store and display a wide assortment of grocery products in singular packag-
es, previously cooled to storage temperature. There is also a DEEP version of the case (ventilated, evaporator at the front,
horizontal display shelves). Our display cabinets ensure universal and efcient display area for all types of commercial
and gastronomic units. Guaranteed temperature inside the display cabinet equals +1ºC/+10ºC with ambient temperature
of +15ºC/+25ºC and relative air humidity of up to 60%.
2.2. Description of the device
SAMOS cases have static cooling, while SAMOS DEEP have dynamic cooling. SAMOS display cabinets have dynamic
or static cooling. All types are equipped with automatic defrosting and electronic thermostat optionally cooperating with
temperature recording module enabling to record and signal too low and too high temperature within the device. There is
also an option with automatic condensate evaporation. Together with corned display cabinets, they may be connected
in sequences. “SAMOS” display cabinets may be ordered in two versions: with internal aggregate or to be connected to
central aggregate (mod/C). “SAMOS” display cabinets are equipped with storage chamber. “SAMOS” display cabinet is
available in stationary or moving version. Our devices are made according to modern technologies and have all certi-
cates required by law.
This sign signies information of particular meaning for user security and for proper device
exploitation.
User manual SAMOS, SAMOS DEEP
