User manual Samos, Samos Deepwww.igloo.pl
3. PREPARING THE DEVICE FOR EXPLOITATION
3.1. Requirements concerning the place of installation
• Verify whether the cross section of feeding conduits is proper for power consumption of the installed device.
• It is forbidden to connect the device by extension rods or dividers.
• The device should be connected to the separate, properly made electric circuit with plug-in socket with protecting pin
(according to PBUE /Regulations concerning Electric Equipment Construction/)
The device may be actuated solely after conrmation of the re protection efciency with results of meas-
ures performed according to binding regulations!
3.2. Connection and actuation
• Unpack the device and remove the wooden platform from the basis (does not concern moving devices) Fig.2 (p.14
• Place the display cabinet on an even basis, which is hard enough, and then level it with feet.
• Remove the protection foil from the elements of the device
• If the user shall obtain a device partially disassembled to secure it during transportation, perform the following op-
erations:
1. Mount display shelves
2. Mount glass sides.
3. Put the shelves on the bars g
4. Install front glass
5. Mount night screens.
6. Place the drip tray on the base of the device, under the siphon, according to g. 4/3 (p. 14) or g. 5/3 (p. 14)
• The rst cleaning of the device should be provide right after unpacking, and before turning it on. The unit should
be cleaned with water at a temperature not exceeding 40°C with a neutral detergent. For washing and cleaning
the equipment it is prohibited to use products containing chlorine and sodium varieties, which destroy the protec-
tive layer and components of the device! Any residue of adhesives or silicone on metal elements should be re-
moved only with extraction naphtha (not applicable to items made of plastic !). Do not use other organic solvents.
SAMOS DEEP 1.25 230/50 1,8 17,0 5,7 -
SAMOS DEEP 1.56 230/50 1,8 22,4 5,8 -
SAMOS DEEP 1.88
230/50
2,6
28,8
8,5
-
SAMOS DEEP 2.50
230/50
3,0
34,0
9,5
-
SAMOS DEEP 3.13 230/50 4,9 48,4 12,3 -
SAMOS DEEP 3.75 230/50 4,9 51 15,9 -
SAMOS DEEP NW90
230/50
1,1
8,5
4,4
-
SAMOS DEEP NZ90
230/50
1,4
7,2
4,4
-
SAMOS DEEP 0.94-mod/C
230/50
0,1
14,4
0,3
400
SAMOS DEEP 1.25-mod/C 230/50 0,1 17,0 0,3 400
SAMOS DEEP 1.56-mod/C 230/50 0,1 22,4 0,4 400
SAMOS DEEP 1.88-mod/C
230/50
0,2
28,8
0,6
400
SAMOS DEEP 2.50-mod/C
230/50
0,2
34,0
0,7
400
SAMOS DEEP 3.13-mod/C 230/50 0,2 48,4 0,7 400
SAMOS DEEP 3.75-mod/C 230/50 0,3 51 1,0 400
SAMOS DEEP NW90-mod/C
230/50
0,1
8,5
0,2
400
SAMOS DEEP NZ90-mod/C
230/50
0,1
7,2
0,2
400
