iHome AUTOVAC ECLIPSE iHRV10 - AUTOVAC INDICATORS; POWER BUTTON; HOME BUTTON; WIFI INDICATOR

1
2
3
1
4
3
2
• Hold to turn on/off.
• Press to start/pause cleaning.
• Flashingbluelight:Poweringon/conguringnetwork/upgradingrmware.
• Solidbluelight:Poweredon/normalworkingstate.
• Flashing yellow light: Low battery/recharging.
• Flashing green light: Charging.
• Solid green light: Fully charged.
• Flashing red light: Error state.
• Light off: Off/sleeping.
• Presstoreturntochargingdock
for recharging.
POWER BUTTON POWER/HOME LED STATES
WIFI INDICATOR STATES
CHARGING INDICATOR LED STATES
HOME BUTTON
CHARGING INDICATOR
WIFI INDICATOR
• Flashingwhitelight:Networkcongurationmode.
• Solidwhitelight:Wiconnected.
• Lightoff:Widisconnected/Networkcongurationfailure.
• LED will remain solid green when connected to wall power.
4
5
AUTOVAC INDICATORS
