IK Multimedia iLoud User Manual

ENGLISH ENGLISH
Safety Information
•Toreduceriskofinternaldamageorelectricshock,never
expose the unit to rain, moisture or excessive humidity.
Never let liquid get into the unit, especially on the front
(speaker)sideortherearbass-reexport.
•Thepowersupplyunitincludedintheboxisdesignedfor
indooruseonly.
•Neverletanyobjectenterintotherearbass-reexport.
•Neverexposetheunittoatemperaturehigherthan60°C
(140°F),andneverrechargethebatteryiftheenvironmental
temperatureishigherthan38°C(100°F)orlowerthan0°C.
Thismightstresstheinternalbatteryuptothepointwhere
itcouldbepermanentlydamaged.
•For optimal battery performanceand life,alwaysusethe
unitattemperaturesbetween18°C(65°F)and25°C(77°F).
•NeverattempttoconnectiLoudtoapowersupplydifferent
thantheoneincludedinthebox.Doingsomightdamage
theinternalbatteryandmakeitoverheat,causingpotential
danger.
•Neverstepon,crush,orattempttomodifythepowercords
connectedtothepowersupplyunit.
•Disconnecttheunitfromthemainpowersupplylinewhenit
won’tbeusedforlongtime.
•Disconnecttheunitfromthemainpowersupplylineduring
alightningstorm.
•There are no user-serviceable parts inside iLoud, never
opentheunit.
•Allservicingshouldbereferredtoqualiedpersonnelonly.
•The speakers contained in iLoud have magnets, which
couldbedangerousifyouhaveapacemaker.
iLoud
Thank you for purchasing iLoud, the rst studio-quality
portablespeakerdesignedformusicians.
Yourpackagecontains:
•iLoud
•iLoudCharger
•1/8”TRRSaudiocable,1m(3.33’)
•QuickStartGuide
•RegistrationCard
While there are hundreds of portable speakers on the
market, none of them were developed with musicians in
mind—untilnow.MeetiLoud—therstportablespeaker
for musicians. We’ve created a portable speaker that
combinessuperiorpowerwithspectacularaudioresolution
and amazing low end. For the rst time, musicians can
haveaportablespeakerthatsoundslikeastudiomonitor,
and allows them to create high-quality compositions and
accuratemixesonthego.
Features
iLoud is designed to provide hi-, studio-monitor-quality
sound,inasurprisinglysmallpackagethatcaneasilytin
abag.
Itsfull40W ofpower willprovideenoughvolumeto make
iLoudseemlikeaspeakerthat’sthreetimesbiggerthanitis!
WithiLoudyoucanmonitoryourmusiccreationsmadeon
thegowithyouriPhone,iPador anyothermobiledevice,
likealaptopcomputer,withthecondencethatyoucantrust
whatyou’rehearingtobesonicallyaccurate.
Theincrediblypristineandtransparentsoundreproductionof
iLoudisaresultofitstwo-waybi-ampedspeakersystem,with
anactivedigitalcrossoverandtimealignment.Theonboard
DSPprovidesfullcontrolofthesystemunderallconditions,
makingsureiLoudwillsounditsbestatanyvolumelevel.
iLoud’shigh-performanceLi-Ionrechargeablebatteryallows
forhoursofcontinuousplaybackbeforeyouneedtorecharge,
andthebuilt-inauto-standbyfunctionsavesbatterycharge
whennoaudiohasbeenfedtoiLoudforseveralminutes.
iLoudprovidesananalog1/8”stereolineinputthatletsyou
connectastereoline-levelsoundsourcefromdevicessuch
assmart phones,tablets,MP3 players, laptopcomputers,
receiversandsoon.
You can also stream high-quality music to iLoud via
Bluetooth.iLoudwillacceptuptotwopaireddevicesatthe
sametime,allowingaudiostreamingfromoneortheother
withouthavingto“pair”everytimeyouswitchdevices.
Thebuilt-in“iRig”circuitallowsyoutoconnectiLoudtoan
iPhone, iPodtouch or iPadusing the included 1/8”TRRS
cable, and play guitaror singinto a dynamic microphone
while using the AmpliTube or VocaLive industry-standard
audioFXapps.
Register Your iLoud
Byregistering,youcanaccesstechnicalsupport, activate
your warranty, and receive free JamPoints™, which will
beadded toyouraccount. JamPointsallowyoutoobtain
discountsonfuture IKpurchases!Registeringalso keeps
youup-to-datewithproductnewsandupdateinformation.
Registerat:www.ikmultimedia.com/registration
Setup
WerecommendfullychargingyouriLoudthersttimeyou
useit.Todoso,connecttheincludedChargertoamains
socketandthentoiLoud(11).Thefastestwaytochargeis
toleaveiLoudOFFwhilecharging.YoucanlistentoiLoud
whilecharging—justturnitON—butthechargingprocess
willtakelonger.A fullcharge(with iLoud off)takes about
twohours,butbecauseiLoudisdeliveredpartiallycharged,
yourrstchargewilltakelessthanthat.
Duringthechargingphase,theLED(9)onthebackofiLoud
willbeORANGE.Oncethechargehascompleteditwillturn
GREEN.
Oncecharged, usingiLoudconnected totheCharger will
notdrainthebattery.Wheneverit’sconvenient,useiLoud
withthechargerconnected.
WhentheiLoudbatteryisgettinglow,theLED(9)onthe
backpanelwillturnRED.TheREDlightonthefrontpanel

IK Multimedia iLoud Specifications

General

Magnet type	Neodymium
Speaker type	2-way
Woofer diameter	76.2 mm
Tweeter diameter	19.05 mm
Number of drivers	4
Number of speakers	1
Audio output channels	2.0 channels
Amplifier class	D
Impedance	- Ω
Frequency range	50 - 20000 Hz
RMS rated power	40 W
Wi-Fi	No
AUX in	Yes
Bluetooth profiles	A2DP
Connectivity technology	Wired & Wireless
Product type	Stereo portable speaker
Product color	Black
LED indicators	Power
Volume control	Rotary
Recommended usage	Universal
Power source type	Battery
Battery life (max)	10 h
Cables included	AC, Audio (3.5mm)
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	60 mm
Width	250 mm
Height	160 mm
Weight	1330 g
