10 AA-2194876-2
A
B
A
B
Figure 7
Screws to attach the bottom trim are supplied with
the oven. The trims are easier to install if the door
is removed. See the User manual for instructions on
how to remove the oven door.
A. Place the air diverter (A) in place as shown
in Figure 7. Line up screw locations and attach
both ends.
B. Place the color matched trim (B) in place as
shown. Line up screw locations and attach both
ends.
7. Install the Bottom Trim
Bottom trims must be installed for the oven to
function properly. DO NOT operate the oven
without bottom oven trims installed. Do not use
wood or any other trim that is not manufactured
for use with this model. Operating the appliance
without manufacturer's bottom trims properly
installed may cause personal injury and may
damage cabinetry or the appliance.
CAUTION!
