IKEA SKYTTA - SKYTTA System Components Overview

7
2
4
5
3
14
15
6
8
16
7
10
12
9
13
1
1. Wood Beam
2. Flange Screews
3. Ceiling Rail
4. Top Rail Cover
5. Floor Rail
10. Door
11. Door Handle
11
6. Soft Close
7. Soft Close Activators
8. Guide Pin FTC
9. Wheel Fitting
13. Ceiling Height Reducer (optional)
12. Door Panels
14. Top Cover Panel (optional)
15. Stop Bar (optional)
16. Home Position (optional)
Since SKYTTA packages are picked together for each
system combination you will have some dierent
packages. Below is an overview of the dierent pack-
ages and parts. Make sure you have everything you
need before starting the assembly.
Main Assembly Instruction for the system is to be
found in the tting package for the end doors.
This main Assembly Instruction will refer to other
Assembly Instructions when it is time for that step.
SKYTTA parts
1. Wood beam
2. Flange screws
3. Ceiling rail
4. Top cover
5. Floor rail
6. Soft close
7. Soft close activators
8. Guide pin FTC
9. Wheel tting
10. Door
11. Door handle
12. Door panels
13. Stop bar (optional)
14. Ceiling height reducer
(optional)
15. Top cover (optional)
16. Home position
