SPECIFICATIONS
MOTOR
Engine Type air-cooled, 2-cycle
Displacement 31 cm³
Maximum engine power in accordance with ISO8893 0,75 kW
Max. engine speed 7.800 min
-1
Idle speed 3.800 min
-1
Ignition type CDI
Spark plug gap 0,5 mm
Petrol/Oil ratio 40:1
Carburettor diaphragm, all-position
Starter auto recoil
Petrol tank capacity 415 ml
BLOWER/VACUUM
Throttle control rocker lever, stationary
Blower velocity up to 250 km/h
Max. suction capacity up to 12 m
3
/min
Mulching ratio up to 10:1
Vacuum bag capacity 45 litres
Shoulder harness single quick-snap
Weight (without petrol) 6,47 kg
The following levels were measured with the unit in running in blower mode: EN 15503:2009
Max. vibration level (operating RPM) 14,8 m/s
2
K=1,5 m/s
2
Sound pressure level L
pA
(operating RPM) 92,6 dB(A)
K=3,0 dB(A)
Sound power level L
wA
(operating RPM) 108,0 dB(A)
Noise emission information in accordance with the German Product Safety Act (ProdSG) and the EC Machine Directive:
The noise level at the workplace may exceed 80 dB (A). In this case, noise protection measures for the operator
are required (e.g., wearing of ear protection).
GB-16
Petrol Leaf Blower/Vacuum IBLS 31
