GUIDE TO THE MANUAL
This manual has been produced to serve as a guide for users of the NOVA 2000 key-cutting machine.
Read it carefully; it is essential if you wish to operate your machine safely and efficiently.
Consultation
The contents of the manual are divided into sections relating to:
- Transport and handling ...............................................................................................Ch. 1
- Description of machine and safety devices ................................................................Ch. 2-3-4
- Proper use of machine ...............................................................................................Ch. 5-6-7
- Maintenance ...............................................................................................................Ch. 8-9-10
Technical terms
Common technical terms are used in this manual. To assist those with little experience of key cutting,
below is an illustration of the terms used for the different parts of keys.
Fig. 1
1) Head
2) Rim
3) Stop
4) Stem
5) Tip
6) Back
7) Cuts
2
1
5
7
3
4
6
1
5
7
3
DIMPLE KEY LASER (SIDEWINDER) TYPE KEY
keys with holes of different
dimensions, depths, positions
and shapes.
LASER is the name given to the
special sidewinder milled keys.
