Enter new DH+ Node address (Octal):
To edit the DH+ baud rate, press “2” ENTER↵ and select a value and press
ENTER↵..
Enter Selection: 2
DH+ Speed: [57.6 KBaud]
1.) 57.6K Baud
2.) 115.2K Baud
3.) 230.4K Baud
4.) Autobaud Detection
5.) or <CR> Keep as Configured and Return to Online
Parameters Menu
To edit the parameters for the serial port, press “3” ENTER↵ and the following
submenu is displayed. Each of the parameters can be changed with corresponding
submenus. To save the serial settings, press “7” ENTER↵.
Enter Selection: 3
Serial Parameters:
1.) Baud Rate 9600
2.) Parity NONE
3.) Data Bits 8
4.) Stop Bits 1
5.) Interface (RS232/422/485) RS232
6.) RS232 RTS/CTS Handshaking NONE
7.) Return to Online Parameters Menu
Enter Selection:
The following DF1 protocol parameters can be edited with option 4 and their associated
submenus.
Enter Selection: 4
DF1 Protocol Parameters:
1.) Error Checking Mode BCC
2.) Duplex Protocol FULL
3.) PASS/EXECUTE Diagnostics PASS
4.) Return to Online Parameters Menu
Enter Selection:
