Illustra Flex 3MP and 8MP Outdoor Bullet Quick Start Guide
8200-1456-03 G0 2
Figure 3 on page 2 and Figure 4 on page 3 illustrates dimensions and physical properties of the units
as well as a pictorial index of the camera connectors. Descriptions of these connectors are available
in Table 5 on Page 3.
Note:The connector cable of the Outdoor Bullet Camera should be contained in a conduit suitable for
outdoor use.
Figure 3 3MP Camera (IFS03B1BNWIT) dimensions (mm) and pictorial index
