Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
11 8200-1456-02 E0
Table 16 Pictorial index descriptions
Index number Description
1 Camera bottom case
2 IR board
3 Tilt adjustment bracket
4 Camera top case
5 Loosen the screw to take off camera housing
6 Dome cover
Figure 17 Pin definitions of the unit
