Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
13 8200-1456-02 E0
Installation
In the box
Check everything in the packing box matches to the order form and the packing slip. In addition to
this guide, items below are included in the packing box.
• 1 Network Outdoor Dome Camera
• 1 printed Quick Start Guide
• 1 printed Regulatory document
• 1 NTSC/PAL output female BNC cable
• 1 adapter plate (for pendant cap)
• 3 7mm adapter plate screws
• Desiccant
• 1 Torx 10 Security L-Key
• 3 18mm plastic anchors and screws
• 1 installation template sticker
• 2 8mm pendant cap screws
Contact your dealer if any item is missing.
Note:The adapter plate is for an installation with a ADCi6DPCAPI (W/B) pendant cap and can also
be used to mount to a standard dual gang electrical box.
Installation tools
The following tools assist with installation:
• a drill
• screwdrivers
• wire cutters
