Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
17 8200-1456-02 E0
Figure 23 Adjusting the position of the camera
NOTE
For outdoor Dome camera series:
Users can adjust zoom level and focus level using the Illustra Connect Web User
Interface.
- End -
Procedure 11 Locking the Camera
Step Action
1 Use a soft, lint-free cloth to wipe the dome cover and remove fingerprints.
2 Attach the inner liner and camera housing.
3 Turn the power on after you have install the unit.
- End -
Procedure 12 Applying the desiccant
Step Action
1 Remove the papers from the back of the desiccant.
2 Attach to the interior side of the tilt adjuster as seen in the image below.
Figure 24 Location for desiccant application
