MACHINE PARTS
A
B
C
E
F
F1
F2
G
H
I
L
D
A LEVER TO OPEN/CLOSE CAPSULE
COMPARTMENT
B CAPSULE COMPARTMENT (internal)
C BREW GROUP
D DATA PLATE (on base)
E CUP HOLDING SURFACE
F LIGHTED TOUCH SCREEN
F1 ESPRESSO
F2 LONG ESPRESSO
M
N
G USED CAPSULE CONTAINER
(residual liquid after brewing).
H CUP STAND
I DRIP TRAY (internal)
L WATER TANK
M MAIN ON/OFF SWITCH
N POWER CORD
