PIÈCES COMPOSANT LA MACHINE
A
B
C
E
F
F1
F2
G
H
I
L
D
A LEVIER OUVERTURE/FERMETURE
COMPARTIMENT POUR CAPSULES
B COMPARTIMENT POUR CAPSULES (interne)
C GROUPE ÉCOULEMENT CAFÉ
D PLAQUE SIGNALÉTIQUE (sous la base)
E SUPPORT TASSES
F TOUCHES TACTILES LUMINEUSES
F1 CAFÉ ESPRESSO
F2 CAFÉ ALLONGÉ
M
N
G COMPARTIMENT POUR CAPSULES USAGÉES
(contenant les residus liquides).
H SUPPORT TASSE
I BAC DE RÉCUPÉRATION RÉSIDUS D’EAU
(interne)
L RÉSERVOIR D’EAU
M INTERRUPTEUR GÉNÉRAL
N CÂBLE D’ALIMENTATION
