D Image counter: shows the number of images currently stored (456)
in the Image Bank and how many images there are left until the
Image Bank is full (703).
E Shutter time: shows the current setting. The shutter time controls
how long the CCD will be exposed for the current image.
See page 22 for details about setting the shutter time.
F "Battery Low": appears and flashes to indicate low charge state of
the Image Bank battery when operating the Ixpress system
disconnected from the computer.
G "ISO high": appears and flashes to indicate that current ISO setting
is higher than 50 and thereby increasing the risk of noise in the
captured image.
H Exposure Info: shows a histogram curve indicating the overall
brightness and contrast of the current shot - see “Taking Pictures” on
page 43 for details.
From the Setup menu you can select whether or not to display the
histogram - see "Setup" on page 27 for details.
J Status Indicator: indicates that power is supplied to the camera back
and the color indicates the current status of the camera back:
Red = Error, Yellow = Busy, and Green = Ready.
K OK button: use to enter "Browse" function and to change/confirm
settings - see "Using the Control Panel" on page 16 for details.
L Browse/Scroll button: use to browse through images in the Image
Bank and to scroll through menu items - see "Using the Control
Panel" on page 16 for details.
Use the button to enter the zoom function and to move the zoom box
around - see "Zooming" on page 17 for details.
The button also can be set to function as an exposure button - see
"Device Settings Menu" on page 22 for details.
M MENU button: displays the "Menu" from where you can make the
various device settings - see "Using the Control Panel" on page 16 for
details.
User's Guide - Imacon Ixpress
English
The Ixpress Camera Back
15
The Ixpress Control Panel
