Page #7 background image
IP400, IP500 & IP600 5
ELECTRICAL CONNECTION
Standard machines are supplied as single phase units. 3 phase machines are supplied as
variation to specification.
Before making the electrical connection check that the voltage of the supply is suitable for
the machine. The details of the machine are on a rating label located on the rear panel.
All machines should be connected to a switched outlet.
Machine Type
Machine termination
Supply termination
Single phase machines
230-1-50
220/240-1-60
110-1-60
Mains lead terminated with a moulded
plug, fitted with 10 Amp fuse
13 Amp switched
socket
3 phase, 4 wire
220-3-60
440-3-60
Mains lead free end, wires marked:
L1 (black)
L2 (black)
L3 (black)
E (green / yellow)
Fused isolator switch
rated at 10 Amps per
phase.
3 phase, 5 wire
415-3-50
220-3-50
360/440-3-50
380/415-3-50
Mains lead free end, wires marked:
L1 (black)
L2 (black)
L3 (black)
N (blue)
E (green / yellow)
Fused isolator rated
at 10 Amps per
phase
Note: On 3 phase machines to ensure that the Power Pack Motor rotates in the correct
direction, connect the leads of the mains cable to the corresponding wires of the mains
supply fused isolator switch. After connection to the isolator switch, switch on the isolator
and press the green start button on the machine. If the hydraulic power pack runs but the
ram does not operate the machine must be stopped immediately. Switch off at the isolator
and exchange any two incoming phase wires.
WARNING - THIS MACHINE MUST BE EARTHED
