IMC MISTRAL 13 Series User Manual

MISTRAL M60, M90, M135 AND TC60 27
SPARE PARTS LIST
Mistral M60
–
Series 1
1
Mistral M90
–
Series 1
1
Part No
Description
Part No
Description
A11/276 Door Gasket A11/275 Door Gasket
A12/073 Pilaster Strip A12/073 Pilaster Strip
A12/091 Z1 Shelf A12/092 Z1 Shelf
A12/100 Wine Shelf A12/101 Wine Shelf
A12/036 Shelf Clip (4 per shelf) A12/036 Shelf Clip (6 per shelf)
A19/027 Glider Foot A19/027 Glider Foot
A21/011 Lock, clip & keys A21/011 Lock, clip & keys
E76/221
Access panel
E76/221
Access panel
G30/420 Electronic Controller G30/420 Electronic Controller
G30/450 Electronic Controller 115V G30/450 Electronic Controller 115V
G42/020 Plastic Drip Tray G42/020 Plastic Drip Tray
G60/348 M1 Mains Cable G60/348 M1 Mains Cable
G60/349
Mains cable EU plug
G60/349
Mains cable EU plug
S77/007 Refrigeration Pack S77/003 Refrigeration Pack
S
77
/007
-
220
Refrigeration Pack 220V
-
60Hz
S7
7
/003
-
220
Refrigeration Pack 220V
-
60Hz
S77/007-115 Refrigeration Pack 115V-60Hz S77/003-115 Refrigeration Pack 115V-60Hz
J09/054 Condenser/fan motor assembly J09/046 Condenser/fan motor assembly
G40/239 Condenser fan – motor only
J09/026 Evaporator J09/045 Evaporator
J09/007 Service Drier J09/007 Service Drier
X08/057 (2mtr) Capillary M60 X08/057 (3mtr) Capillary M90
G96/049
Evaporator Fan
G96/049
Evaporator Fan
G96/052 Evaporator Fan 115V G96/052 Evaporator Fan 115V
G50/070 Fluorescent Light 8W T5 G50/071 Fluorescent Light 14W T5
S77/014 Door Assembly LH M60 S77/016 Door Assembly LH M90
S77/015 Door Assembly RH M60 S77/017 Door Assembly RH M90
