28 MISTRAL M60, M90, M135 AND TC60
SPARE PARTS LIST CONT..
HIGH AMBIENT VERSIONS – M60HA & M90HA
Mistral M60
HA
–
Series 1
Mistral M90
HA
–
Series 1
Part No
Description
Part No
Description
A11/276 Door Gasket A11/275 Door Gasket
A12/073 Pilaster Strip A12/073 Pilaster Strip
A12/091 Z1
Shelf
A12/092 Z1
Shelf
A12/100 Wine Shelf A12/101 Wine Shelf
A12/036 Shelf Clip (4 per shelf) A12/036 Shelf Clip (6 per shelf)
A19/027 Glider Foot A19/027 Glider Foot
A21/011 Lock, clip & keys A21/011 Lock, clip & keys
E7
7
/2
70
Access panel
E77/270
Access panel
G30/420 Electronic Controller G30/420 Electronic Controller
G42/045 Plastic Drip Tray G42/045 Plastic Drip Tray
G60/348 M1
Mains Cable
G60/348 M1
Mains Cable
G60/349 Mains cable EU plug G60/349 Mains cable EU plug
S77/037 Refrigeration Pack HA S77/047 Refrigeration Pack HA
J09/049 Condenser/fan motor assembly J09/046 Condenser/fan motor assembly
G40/239 Condenser fan – motor only
J09/026 Evaporator J09/045 Evaporator
J09/007 Service Drier J09/007 Service Drier
X08/057 (2mtr)
Capillary M60
X08/057 (3mtr)
Capillary M90
G96/049 Evaporator Fan G96/049 Evaporator Fan
G96/052 Evaporator Fan 115V G96/052 Evaporator Fan 115V
G50/070
Fluorescent Light 8W T5
G50/071
Fluorescent Light 14W T5
S77/049 Door Assy LH M60HA with heat
trace
S77/044 Door Assy LH M90HA with heat
trace
S77/036 Door Assy RH M60HA with heat
trace
S77/043 Door Assy RH M90HA with heat
trace
