IME CONTO D2 - Factory settings; Network Connection

10/15 10783390 WEB E cod.CE20195A.
9
Conto D2
Factory settings
Cd: 1000
1
Ad: 255
1
br: 9600
1
Py: nonE
2
PU: 10Wh
2
Pd: 100msec
th: 0,4%
rR: YES
1
Only RS485 communication is present
2
Only Pulse output energy is present
RS458
A
Tx /Rx
+
B
Tx /Rx
-
GND
RS232
Tx
Rx
GND
220Ω
220Ω
33 34
35
RS 485
Rx / Tx GND
33 34
35
RS 485
Rx / Tx GND
33 34
35
RS 485
Rx / Tx GND
Network Connection
Last network Conto D2
NETWORK
