4. Device Components
4.1 Bottom
The reference electrode connector is at the bottom left side of the device. The PPG sensor and
USB-C connector is at the bottom right side of the device. You can connect the reference
electrode and PPG sensor through the connector. The device can be charged through the USB-C
connector.
Name
Model Name
Description
1
Reference electrode
REF-W01
Ear clip sensor serving as reference point for
EEG measurement
