5.4 Putting on iSyncWave and Measuring EEG
1) Find a comfortable environment and position to measure EEG.
2) Go to the Settings page and set the measurement time.
3) Put on the iSyncWave device on patient/subject’s head so that the electrodes are in good
contact with the scalp. Put on the chin strap to secure the device.
4) Check for the electrode impedance on the iSyncWave app.
5) After checking the electrode impedance, start measuring EEG.
5.5 Shutting down iSyncWave
Press the power button and hold for more than 2 seconds to shut down the device.
5.6 Software Display
Horizontal Scale: (EEG scale test: 4seconds, EEG record: 5seconds)
* Horizontal Scale can’t be adjusted
Vertical Scale: 20,30, 50, 70, 100, 150, 200, 300, 500, 700 μV
* Vertical Scale can be adjusted and selected
Montage: Ear reference, Common average reference, Longitudinal, Transverse
