Blacktip II - User Manual
IMENCO AS Visiting Address: Kophaug 3, 5570 Aksdal, Norway Office: +47 52 86 41 00 imenco@imenco.com
Org No: 923 005 749 MVA Postal Address: PO. Box 2143, 5504 Haugesund, Norway Fax: +47 52 86 41 01 www.imenco.com
5
2 Technical Specifications
Image Resolution 1080P @ 25/30 – PAL / NTSC (CVBS)
Video output format Composite video
Minimum illumination 0,5 lux
Zoom 10x optical (+16x digital) F 1.8 to 3.4
View angle in water (wide) 43° hor.
Minimum Working Distance 0.01 m in water @ Zoom 1x
Front Port - Camera Sapphire glass
Housing Titanium
Depth rating 4.000 MSW
Camera control RS232 / RS485, Bipolar / Tristate
Standard connectors 5507-1508 / MCBH/ CS-MSAJ-9-BCR *
Power requirements 24VDC (12 – 36) – 5W
Main dimensions (ex conn.) Ø 58 x 143
Mass in air / water 0,8kg / 0,5kg
Operating temperature range -5°C to +50°C
