Blacktip II - User Manual
IMENCO AS Visiting Address: Kophaug 3, 5570 Aksdal, Norway Office: +47 52 86 41 00 imenco@imenco.com
Org No: 923 005 749 MVA Postal Address: PO. Box 2143, 5504 Haugesund, Norway Fax: +47 52 86 41 01 www.imenco.com
6
2.1 Power
The camera is powered by a DC voltage applied to two power connector pins. The circuit
includes reverse polarity protection, but the polarity must be correct for the camera to
power up. See the accompanying QC document for the specific pin-out of your product.
The camera housing is not connected to any pin in the subsea connector or any terminal
of the electrical circuits inside the camera.
IMPORTANT! The camera housing is not connected to Protective Earth.
3 Installation Instructions
Make sure that Imenco’s Terms & Conditions are followed when using this product.
3.1 Unpacking and testing
When having received the camera do a visual inspection for damage of the packet or
any of the parts.
The packet should include:
• Blacktip II Camera
• User manual, this document
• Case
• Memory stick, with software and manual for RS232 / RS485 versions
• Pressure Test Certificate
• QC document
• Test Interface Box (optional)
• Dummy Connector (optional)
