Immergas Maior Eolo 24 4E - Page 11

11
INSTALLERUSER
MAINTENANCE TECHNICIAN
Shutter regulation table
Maior Eolo 24 4E.
Shutter regulation table
Maior Eolo 28 4E.
Shutter regulation table
Maior Eolo 32 4E.
Flue gas shutter notch
Type of installation
(duct length in metres)
1 3 4 5 6 10
Ø60/100 horizontal concentric kit - - Da 0 a 0,5 Da 0,5 a 1,5 - Da 1,5 a 3,0
Ø60/100 vertical concentric kit - - Da 0 a 2,2 Da 2,2 a 3,7 - Da 3,7 a 4,7
Ø80/125 horizontal concentric kit - - Da 0 a 0,5 Da 0,5 a 4,6 - Da 4,6 a 7,4
Ø80/125 vertical concentric kit - - Da 0 a 5,4 Da 5,4 a 9,5 - Da 9,5 a 12,2
Ø80 vertical separator kit without bends *Da 0 a 20 *Da 20 a 40 **Da 0 a 22 - - **Da 22 a 32
Ø80 horizontal separator kit with two bend *Da 0 a 16 *Da 16 a 35 **Da 0 a 17 - - **Da 17 a 28
Direct intake kit and Ø80 drain in B
22
conguration - - Da 0 a 1 - Da 1 a 12 -
* ese maximum extension values are considered intake with 1 metre drain pipe
** ese maximum extension values are considered in draining with 1 metre intake pipe and Ø44 diaphragm on the intake hole.
Type of installation
(duct length in metres)
2 4 7 10
Ø60/100 horizontal concentric kit - Da 0 a 0,5 Da 0,5 a 1,5 Da 1,5 a 3,0
Ø60/100 vertical concentric kit - Da 0 a 2,2 Da 2,2 a 3,7 Da 3,7 a 4,7
Ø80/125 horizontal concentric kit - Da 0 a 0,5 Da 0,5 a 4,6 Da 4,6 a 7,4
Ø80/125 vertical concentric kit - Da 0 a 5,4 Da 5,4 a 9,5 Da 9,5 a 12,2
Ø80 vertical separator kit without bends *Da 0 a 20 *Da 20 a 40 **Da 0 a 22 ** Da 22 a 32
Ø80 horizontal separator kit with two bend *Da 0 a 16 *Da 16 a 35 **Da 0 a 17 ** Da 17 a 28
Direct intake kit and Ø80 drain in B
22
conguration Da 0 a 1 - Da 1 a 12 -
* ese maximum extension values are considered intake with 1 metre drain pipe
** ese maximum extension values are considered in draining with 1 metre intake pipe and Ø 50 diaphragm on the intake hole.
Type of installation
(duct length in metres)
3 4 5 6 10
Ø60/100 horizontal concentric kit - - Da 0 a 0,5 Da 0,5 a 1,5 Da 1,5 a 3,0
Ø60/100 vertical concentric kit - - Da 0 a 2,2 Da 2,2 a 3,7 Da 3,7 a 4,7
Ø80/125 horizontal concentric kit - - Da 0 a 0,5 Da 0,5 a 4,6 Da 4,6 a 7,4
Ø80/125 vertical concentric kit - - Da 0 a 5,4 Da 5,4 a 9,5 Da 9,5 a 12,2
Ø80 vertical separator kit without bends *Da 0 a 20 *Da 20 a 40 **Da 0 a 22 - **Da 22 a 32
Ø80 horizontal separator kit with two bend *Da 0 a 16 *Da 16 a 35 **Da 0 a 17 - **Da 17 a 28
Direct intake kit and Ø80 drain in B
22
conguration - Da 0 a 1 - Da 1 a 12 -
* ese maximum extension values are considered intake with 1 metre drain pipe
** ese maximum extension values are considered in draining with 1 metre intake pipe and Ø 50 diaphragm on the intake hole.
