3.18 VARIABLE HEAT OUTPUT.
N.B.: the pressures indicated in the table repre-
sent the dierence in existing pressures between
the gas valve outlet and the combustion chamber.
e adjustments should therefore, be carried
out using a dierential manometer (small “U”-
shaped column or digital manometer) with the
probes inserted in the pressure test gas valve
outlet and on the sealed chamber positive pres-
sure test. e power data in the table has been
obtained with intake-exhaust pipe measuring
0.5m in length. Gas ow rates refer to heating
power below a temperature of 15°C and at a
pressure of 1013 mbar. Burner pressure values
refer to use of gas at 15°C.
Maior Eolo 24 4E.
Maior Eolo 28 4E.
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
TIMER
+
D.H.W.
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
(kW) (kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
24,0 20640 2,73 12,30 125,4 2,04 28,50 290,6 2,00 36,70 374,2
23,0 19780 2,62 11,42 116,5 1,96 26,23 267,5 1,92 33,75 344,2
22,2 19120 2,53 10,77 109,8 1,89 24,57 250,5 1,86 31,59 322,1
21,0 18060 2,40 9,77 99,6 1,79 22,03 224,7 1,76 28,30 288,6
20,0 17200 2,29 8,99 91,6 1,71 20,10 204,9 1,68 25,79 263,0
19,0 16340 2,18 8,24 84,0 1,63 18,26 186,2 1,60 23,42 238,8
18,0 15480 2,07 7,52 76,7 1,55 16,52 168,5 1,52 21,17 215,9
17,0 14620 1,96 6,82 69,6 1,47 14,88 151,7 1,44 19,05 194,3
16,0 13760 1,85 6,16 62,8 1,38 13,33 135,9 1,36 17,06 174,0
15,0 12900 1,75 5,52 56,3 1,30 11,87 121,0 1,28 15,19 154,9
14,0 12040 1,64 4,91 50,1 1,22 10,50 107,1 1,20 13,44 137,0
13,0 11180 1,53 4,32 44,1 1,14 9,22 94,0 1,12 11,80 120,4
12,0 10320 1,42 3,76 38,3 1,06 8,03 81,8 1,04 10,29 104,9
11,0 9460 1,31 3,22 32,8 0,98 6,92 70,6 0,96 8,89 90,7
10,0 8600 1,20 2,70 27,6 0,89 5,91 60,2 0,88 7,61 77,6
9,3 7998 1,12 2,36 24,0 0,84 5,25 53,5 0,82 6,79 69,2
8,0 6880
D.H.W.
0,97 1,74 17,8 0,73 4,14 42,2 0,71 5,41 55,2
7,0 6020 0,86 1,30 13,3 0,64 3,40 34,7 0,63 4,50 45,9
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
TIMER
+
D.H.W.
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
BURNER
GAS FLOW
RATE
PRESS. NOZZLES
PRESSURE
(kW) (kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
28,0 24080 3,14 11,70 119,3 2,35 28,05 286,1 2,31 35,87 365,8
27,0 23220 3,03 10,91 111,2 2,26 26,32 268,4 2,22 33,41 340,7
26,2 22516 2,94 10,28 104,8 2,19 24,95 254,5 2,16 31,48 321,0
25,0 21500 2,81 9,42 96,1 2,10 23,06 235,2 2,06 28,83 294,0
24,0 20640 2,70 8,73 89,0 2,02 21,52 219,5 1,98 26,71 272,3
23,0 19780 2,59 8,06 82,2 1,94 20,04 204,4 1,90 24,68 251,7
22,0 18920 2,49 7,43 75,8 1,86 18,61 189,8 1,83 22,76 232,1
21,0 18060 2,38 6,82 69,6 1,78 17,24 175,8 1,75 20,92 213,4
20,0 17200 2,27 6,24 63,7 1,70 15,91 162,3 1,67 19,18 195,6
19,0 16340 2,17 5,69 58,0 1,62 14,63 149,2 1,59 17,52 178,6
18,0 15480 2,06 5,16 52,6 1,54 13,39 136,6 1,52 15,94 162,5
17,0 14620 1,96 4,65 47,4 1,46 12,20 124,4 1,44 14,44 147,3
16,0 13760 1,85 4,16 42,4 1,38 11,04 112,6 1,36 13,02 132,8
15,0 12900 1,75 3,70 37,7 1,30 9,93 101,2 1,28 11,67 119,0
14,0 12040 1,64 3,26 33,2 1,23 8,85 90,2 1,21 10,40 106,1
13,0 11180 1,54 2,84 28,9 1,15 7,81 79,6 1,13 9,21 93,9
12,0 10320 1,43 2,44 24,8 1,07 6,80 69,3 1,05 8,08 82,4
11,2 9632 1,34 2,13 21,7 1,00 6,02 61,4 0,98 7,24 73,8
10,0 8600
D.H.W.
1,21 1,70 17,3 0,90 4,89 49,9 0,89 6,06 61,8
9,0 7740 1,10 1,36 13,9 0,82 3,99 40,6 0,81 5,16 52,6
8,5 7310 1,04 1,20 12,2 0,78 3,55 36,2 0,77 4,74 48,3
