33
INSTALLERUSER
MAINTENANCE TECHNICIAN
- Flue gas temperature values refer to an air inlet
temperature of 15°C.
- e data relevant to domestic hot water per-
formance refer to a dynamic inlet pressure of
2 bar and an inlet temperature of 15°C; the
values are measured directly at the boiler outlet
considering that to obtain the data declared
mixing with cold water is necessary.
- e max. sound level emitted during boiler
operation is < 55dBA. e sound level value is
referred to semianechoic chamber tests with
boiler operating at max. heat output, with
extension of ue gas exhaust system according
to product standards.
3.20 TECHNICAL DATA.
Maior Eolo 24 4E Maior Eolo 28 4E Maior Eolo 32 4E
Nominal heat input kW (kcal/h) 25,8 (22194) 29,7 (25536) 34,2 (29433)
DHW minimum heat input kW (kcal/h) 8,1 (6968) 9,9 (8480) 12,2 (10524)
CH minimum heat input kW (kcal/h) 10,6 (9094) 12,7 (10902) 14,8 (12710)
Nominal heat output (useful) kW (kcal/h) 24,0 (20640) 28,0 (24080) 32,0 (27520)
DHW minimum heat output (useful) kW (kcal/h) 7,0 (6020) 8,5 (7310) 10,5 (9030)
CH minimum heat output (useful) kW (kcal/h) 9,3 (7998) 11,2 (9632) 12,9 (11087)
Eciency at nominal heat output % 93,0 94,3 93,5
Eciency at 30% nominal heat output load % 90,5 91,5 90,7
Heat loss at case with burner On/O % 0,50 / 0,75 0,10 / 0,53 0,70 / 0,50
Heat loss at ue with burner On/O % 6,0 / 0,02 5,70 / 0,06 5,80 / 0,04
Central heating circuit max. operating pressure bar 3,0 3,0 3,0
Central heating circuit max. operating temperature °C 90 90 90
Adjustable central heating temperature °C 35 - 85 35 -85 35 - 85
System expansion vessel total volume l 6,8 6,8 6,8
Expansion vessel factory-set pressure bar 1,0 1,0 1,0
Water content in generator l 5,0 5,0 5,0
Water content in l 5,0 5,0 5,0
Total head available with 1000 l/h ow rate kPa (m H
2
O) 26,85 (2,74) 38,42 (3,92) 49,42 (5,04)
Hot water production useful heat output kW (kcal/h) 24,0 (20640) 28,0 (24080) 32,0 (27520)
Domestic hot water adjustable temperature °C 30 - 60 30 - 60 30 -60
Domestic hot water circuit ow limiter at 2 bar l/min 7,1 9,5 11,8
Min. pressure (dynamic) domestic hot water circuit bar 0,3 0,3 0,3
Domestic hot water circuit max. working pressure bar 10,0 10,0 10,0
Minimum D.H.W. ow rate l/min 1,5 1,5 1,5
Specic ow rate (∆T 30°C) l/min 11,9 13,8 16,1
Drawing capacity in continuous duty (∆T 30°C) l/min 11,8 13,7 16,1
Weight of full boiler kg 46,5 46,9 47,4
Weight of empty boiler kg 41,5 41,9 42,4
Electrical connection V/Hz 230 / 50 230 / 50 230 / 50
Power input A 0,75 0,85 0,95
Installed electric power W 140 155 175
Pump consumption W 86 84 106
Fan consumption W 29 46 52
Equipment electrical system protection - IPX5D IPX5D IPX5D
NO
X
class - 3 3 3
Weighted NO
X
mg/kWh 128 107 102
Weighted CO mg/kWh 84 92 63
Type of appliance C12 /C32 / C42 / C52 / C62 / C82 / B22p / B32
Category II2H3+
