STMiN3E ed 09/11 MINI NIKE 3 E
Technical Documentation
Technical Documentation
When the safety temperature is exceeded (100 °C) remove the power
supply to the main coils of the gas valve.
e P.C.B. displays the "02" error code.
It is positioned on the ow pipe at the outlet of the primary heat
exchanger.
Safety thermostat
(E4)
Klixon thermostat
with normally
closed contact
Safety devices and controls
It is powered by the integrated P.C.B. with variable direct current.
It allows you to change the gas pressure in the burner based on the required output.
Gas valve modulator
(Y2)
Outputs
Management and control devices
Allows long distance control of the generator (SUM/WIN switch,
temperature adjustment and indication, alarms display, reset, etc.) and
acts as weekly chrono-thermostat.
If the CAR
V2
is installed the pre-existing X40 jumper must be
eliminated.
Comando Amico Remoto
remote control Version 2
(CAR
V2
) (optional)
See How CAR
V2
operates
