MINI NIKE X 24 3E - Technical Data
Nominal heat input kW (kcal/h) 26.2 (22492)
** DHW minimum heat input kW (kcal/h) 8.3 (7116)
CH minimum heat input kW (kcal/h) 10.9 (9357)
Nominal heat output (useful) kW (kcal/h) 23.8 (20468)
** DHW minimum heat output (useful) kW (kcal/h) 7.0 (6020)
CH minimum heat output (useful) kW (kcal/h) 9.4 (8084)
Eciency at nominal heat output % 91.0
Eciency at 30% nominal heat output load % 89.3
Heat loss at case with burner On/O % 2.30 / 1.20
Heat loss at ue with burner On/O % 6.70 / 0.09
Central heating circuit max. operating pressure bar 3
Central heating circuit max. operating temperature °C 90
Adjustable central heating temperature °C 35 - 85
System expansion vessel total volume l 4.0
Heating expansion tank pre-charge bar 1
Water content in generator l 2.5
Total head available with 1000 l/h ow rate kPa (m H
2
O) 24.52 (2.5)
** Hot water production useful heat output kW (kcal/h) 23.8 (20468)
** Domestic hot water adjustable temperature °C 10 - 60
** Min. pressure (dynamic) domestic hot water circuit bar 0.3
** Domestic hot water circuit max. working pressure bar 10
*Specic capacity “D” UB Immergas 80 l (∆T 30°C) according to EN 625 l/min 20.7
*Specic capacity “D” UB Immergas 105 l (∆T 30°C) according to EN 625 l/min 24.4
*Specic capacity “D” UB Immergas 120 l (∆T 30°C) according to EN 625 l/min 26.7
*Specic capacity “D” UB Immergas 200 l (∆T 30°C) according to EN 625 l/min 35.1
Drawing capacity in continuous duty with UB Immergas (∆T 30°C) l/min 11.1
Weight of full boiler kg 28
Weight of empty boiler kg 25.5
Electrical connection V/Hz 230/50
Power input A 0.44
Installed electric power W 95
Pump consumption W 87
Equipment electrical system protection - IPX4D
NO
X
class - 3
Weighted NO
X
mg/kWh 139
Weighted CO mg/kWh 52
Type of appliance B11BS
Category II2H3+
- Flue temperature values refer to an air inlet temperature of
15°C.
- e data relevant to domestic hot water performance refers
to a dynamic inlet pressure of 2 bar and an inlet temperature
of 15°C; the values are measured directly at the boiler outlet
considering that to obtain the data declared mixing with cold
water is necessary.
- e max. sound level emitted during boiler operation is <
55dBA. e sound level value is referred to semianechoic
chamber tests with boiler operating at max. heat output, with
extension of ue gas exhaust system according to product
standards.
-* Specific flow rate “D”: domestic hot water flow rate
corresponding to an average increase of 30K, which the
boiler can supply in two successive withdrawals.
-** When the boiler is connected to an external storage tank.
