Immergas VICTRIX 20 Plus - Variable Heat Output VICTRIX 20 Plus; Victrix 20 Plus Methane (G20) Performance; Victrix 20 Plus Butane (G30) Performance; Victrix 20 Plus Propane (G31) Performance

29
STVP ed 02/06 VICTRIX Plus
Variable heat output VICTRIX 20 Plus.
Variable heat output VICTRIX 27 Plus.
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
GAS FLOW
-
RATE
BURNER
NOZZLE PRESSURE
BURNER
GAS FLOW-
RATE
BURNER
NOZZLE PRESSURE
BURNER
GAS FLOW-
RATE
BURNER
NOZZLE PRESSURE
BURNER
(kW)
(kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
32.0 27520 3.45 5.05 51.5 2.57 4.81 49.1 2.53 6.61 67.4
31.0 26660 3.34 4.74 48.4 2.49 4.50 45.9 2.45 6.18 63.1
29.0 24940 3.12 4.15 42.4 2.33 3.91 39.9 2.29 5.38 54.9
27.0 23220 2.91 3.61 36.8 2.17 3.37 34.3 2.13 4.63 47.3
25.0 21500 2.69 3.10 31.6 2.01 2.86 29.2 1.98 3.94 40.2
23.0 19780 2.48 2.63 26.8 1.85 2.41 24.5 1.82 3.32 33.8
21.0 18060 2.26 2.20 22.5 1.69 1.99 20.3 1.66 2.75 28.0
19.2 12165 2.06 1.84 18.8 1.54 1.65 16.9 1.52 2.28 23.2
17.0 14620 1.84 1.47 15.0 1.37 1.31 13.3 1.35 1.79 18.3
15.0 12900 1.62 1.16 11.8 1.21 1.03 10.5 1.19 1.40 14.3
13.0 11180 1.41 0.89 9.1 1.05 0.79 8.1 1.03 1.07 10.9
11.0 9460 1.20 0.66 6.8 0.89 0.60 6.1 0.88 0.80 8.1
9.0 7740 0.98 0.47 4.8 0.73 0.45 4.6 0.72 0.58 5.9
6.3 5418 0.69 0.27 2.8 0.52 0.32 3.3 0.51 0.38 3.8
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
GAS FLOW
-
RATE
BURNER
NOZZLE PRESSURE
BURNER
GAS FLOW
-
RATE
BURNER
NOZZLE PRESSURE
BURNER
GAS FLOW
-
RATE
BURNER
NOZZLE PRESSURE
BURNER
(kW)
(kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
23.5 20210 2.54 5.77 58.9 1.89 5.29 54.0 - - -
22.0 18920 2.38 5.09 51.9 1.77 4.59 46.8 - - -
20.0 17200 2.16 4.25 43.3 1.61 3.74 38.2 1.59 5.30 54.1
18.0 15480 1.95 3.50 35.7 1.45 3.00 30.6 1.43 4.30 43.9
16.0 13760 1.74 2.82 28.8 1.29 2.34 23.9 1.28 3.40 34.7
14.0 12040 1.53 2.22 22.7 1.14 1.78 18.1 1.12 2.60 26.5
12.0 10320 1.32 1.69 17.3 0.98 1.30 13.3 0.97 1.90 19.4
10.0 8600 1.11 1.23 12.6 0.82 0.91 9.3 0.81 1.40 14.3
8.0 6880 0.89 0.84 8.6 0.67 0.60 6.1 0.66 0.90 9.2
6.0 5160 0.68 0.52 5.3 0.50 0.38 3.9 0.50 0.60 6.1
4.7 4000 0.53 0.34 3.5 0.39 0.28 2.9 0.39 0.40 4.1
