VICTRIX PRO V2 EU
28
e hydraulic separator (compensator) is a particularly sig-
nicant part inside the hydraulic circuits.
It is an open manifold (2) which places system ow and re-
turn in communication, creating 2 circuits: a primary circuit
(boiler - manifold) and a secondary circuit (manifold-system).
e former circulates by the boiler pump, while the latter runs
on the correct thermal gradient (and therefore the correct
water ow rate), as dened by the system's design.
It is advisable to include a hydraulic compensator (2) every
time the overall ow rate required by the system is greater than
what the boiler is able to supply. e maximum ow rate at
the inlet is the generally adopted sizing method.
e brass sludge collecting lter, with relative inspectable stain-
less steel cartridge, protects the condensation module from
getting clogged with the sludge or build-up from the system.
Attention: e boiler has an electric insulation rating of IPX5D
and can also be installed outdoors, whereas the kit must be
appropriately insulated together with its piping.
1
1
G1"1/2
1
M
R
G2"1/2
3
5
2
3
4
6
G2"1/2
11 HYDRAULIC SEPARATOR KIT FOR VICTRIX PRO V2 EU
SINGLE BOILER
KEY:
1 - Gasket 44 x 34 x 2
2 - Insulated Hydraulic manifold DN 100
3 - Gasket 72 X 55 X 2
4 - 90° tting
5 - Nipple 2"
1
/
2
M-M
6 - Slurry collection brass lter
M - Flow
R - Return
Sludge collection lter head loss graph
Flow rate (l/h)
Head losses (mmw.c.)
Head losses (Pa)
