VICTRIX PRO V2 EU
29
Plate heat exchangers, important components of thermal
systems and hydraulic circuits, consist of a series of plates
appropriately coupled one to the other, which perform uid
separation and thermal exchange between 2 circuits called:
Primary and Secondary.
Designed to maximize countercurrent thermal exchange, they
are made with 4 connections that put the ow lines in com-
munication with the return lines of each circuit (the primary
divided from the secondary).
Circulation is ensured by the generator in the primary circuit,
while there are one or more pumps in the secondary circuit
which, based on the system design, provide the correct temper-
ature dierence so as to exchange the output actually necessary.
It is advisable to insert the plate heat exchanger whenever a
new generator is installed on an existing system.
is keeps the buildup of lth of the existing system from en-
dangering the eciency and operation of the new generators.
Attention: e boiler has an electric insulation rating of IPX5D
and can also be installed outdoors, whereas the kit must be
appropriately insulated together with its piping.
12 PLATE HEAT EXCHANGER KIT FOR VICTRIX PRO V2 EU
SINGLE BOILER
KEY:
F1 - Flow from boiler
F2 - Flow to system
F3 - Return from system
F4 - Return to boiler
F5 - Primary boiler
F6 - Secondary boiler
