VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
31
WATER VOLUMES IN KIT COUPLED WITH:
Model Primary circuit litre content Expansion vessel capacity (litres)
VICTRIX PRO V2 35 EU 7.2 2
VICTRIX PRO V2 55 EU 7.6 2
VICTRIX PRO V2 80 EU 8 2
TECHNICAL DATA
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/60°
Flow rate
Secondary
(m
3
/h)
M/R 70°/55°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 20°C
Secondary
circuit
T 15°C
35
50 80
1.5 2.0 0.13 0.21
5.355 2.3 3.1 0.33 0.52
60 - 68 - 80 3.4 4.6 0.70 1.10
Plate heat ex-
changer coupled
with
VICTRIX PRO
V2 EU (kW)
No.
plates
Maximum
managed
power
(kW)
Flow rate
Primary
(m
3
/h)
M/R 80°/65°
Flow rate
Secondary
(m
3
/h)
M/R 70°/60°
p (m.w.c.) Weight
of heat
exchanger
only (kg)
Primary
circuit
T 15°C
Secondary
circuit
T 10°C
35
50 80
2.0 3.0 0.24 0.47
5.3
55 3.1 4.7 0.59 1.10
60 - 68 - 80 4.6 6.9 1.24 2.40
12.2 PLATE HEAT EXCHANGER KIT FOR VICTRIX PRO V2 35  55  60  68  80 EU SINGLE
BOILER TECHNICAL DATA CODE: 3.033676
0
0,21
0,47
0,84
1,5
2,48
0
0,5
1
1,5
2
2,5
0 2 3 4 4,7 6,9
Perdite di carico (m.c.a.)
Portata (m3/h)
Grafico perdite di carico scambiatore
Victrix Pro 35-55-80 V2
(∆T 15° Lato caldaia/∆T 10° Lato impianto)
Heat exchanger head loss chart
VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
(T 15° Boiler side/T 10° System side)
Flow rate (m3/h)
Head losses (mmw.c.)
