VICTRIX PRO V2 35 - 55 - 60 - 68 - 80 EU
39
14.2 DIMENSIONS CABINET KIT + SINGLE VICTRIX PRO V2 35  55  60  68  80 EU
A
B
Ref. Position Code KIT Quantity
A 3.033681 N° 1
B 3.024295 N° 1
