VICTRIX PRO V2 EU
55
Plate heat conveyors are important components of thermal
systems and hydraulic circuits.
e components consist of a series of plates appropriately
coupled one to the other, which perform uid separation
and thermal exchange between 2 circuits called: Primary and
Secondary.
Designed to maximize countercurrent thermal exchange, they
are made with 4 connections that put the ow lines in com-
munication with the return lines of each circuit (the primary
divided from the secondary).
Circulation is ensured by the generator in the primary circuit,
while there are one or more pumps in the secondary circuit
which, based on the system design, provide the correct tem-
perature dierence (therefore with the right water ow rate)
so as to exchange the output actually necessary.
It is advisable to insert the plate heat exchanger whenever a
new generator is installed on an existing system.
is keeps the buildup of lth of the existing system from en-
dangering the eciency and operation of the new generators.
20 PLATE HEAT CONVEYOR KIT FOR MODULES IN SET CONFIGURATION OPTIONAL
