20.5 DIMENSIONS AND CONNECTIONS WITH RH/LH PLATE HEAT EXCHANGER KIT
FOR VICTRIX PRO V2 35  55 - 60 - 68 - 80 EU
IN SET INSTALLATION CODE: 3.033678
No. of Boilers X (without INAIL safety devices kit) Y
N°2 VICTRIX PRO V2 EU 1531 + (511 kit INAIL) 900
N°3 VICTRIX PRO V2 EU 1991 + (511 kit INAIL) 1360
N°4 VICTRIX PRO V2 EU 2451 + (511 kit INAIL) 1820
N°5 VICTRIX PRO V2 EU 2911 + (511 kit INAIL) 2280
X
597
249
330
383
170
249
379
1720
789
13
220
322
432
522
Y
No. of Boilers X (without INAIL safety devices kit) Y
N°2 VICTRIX PRO V2 EU 1364 + (511 kit INAIL) 900
N°3 VICTRIX PRO V2 EU 1824 + (511 kit INAIL) 1360
N°4 VICTRIX PRO V2 EU 2284 + (511 kit INAIL) 1820
N°5 VICTRIX PRO V2 EU 2744 + (511 kit INAIL) 2280
X
427
789
1720
170
213
13
220
322
432
522
249
379
249330
Y
