VICTRIX PRO V2 EU boilers are type-approved for installa-
tion inside the heating control unit or outside in a sheltered
or uncovered area.
ese generators leave the factory in type “C5 - C8” sealed
chamber and fan assisted conguration.
ey can be adapted to open chamber and fan assisted type
B23 (according to standard UNI EN 1749), using specic kits
for direct air intake from the room in which the appliance is
installed, by means of a suction mushroom or thermoformed
cover and the ue gas is exhausted in a single chimney or
directly outside.
By varying the type of installation the classication of the
boiler also varies:
- Type C sealed chamber and fan assisted conguration,
using specic concentric or split kits, as depicted further on
(from page 76 to page 80).
- Type B open chamber and fan assisted conguration, in
this case too by means of specic kits depicted further on
(from page 81 to page 87).
.
24 FLUE SYSTEMS AND CONFIGURATION
In order to be able to install the concentric kits, it is necessary to remove the factory tted cap on the concentric intake.
24.1 CONCENTRIC KIDS INSTALLATION NOT FORESEEN FOR VICTRIX PRO V2 180 EU
Key:
1 - Screw
2 - Concentric intake cap
2
1
Using the concentric ue kits, the generator takes on the type C sealed chamber and fan assisted conguration.
e concentric terminals indicated on the following pages allow air to be suctioned and ue gas to be exhausted directly
outside the home, regardless of whether intake kits or wall or roof ue exhausts are used.
e horizontal kits can be installed with the rear, right side, le side and front outlet, making sure that the metal plates
or silicone buer wall sealing plates are correctly installed, fastening them appropriately until ush with the inside and
outside wall.
