VICTRIX PRO V2 EU
81
To be able to install the intake stub type kit for type B congurations (open chamber and fan assisted), the factory installed
plug, placed above the sealed chamber next to the ue exhaust ange, must be removed (see image below).
24.5 INSTALLATION OF THE INTAKE STUB PIPE KIT
Key:
1 - Suction cap xing screws
2 - Intake cap
3 - Stub pipe kit xing screws
4 - Intake stub pipe
5 - Stub pipe gasket
is kit allows you to use pipes for ow exhaust only, as the generator takes on the type B open chamber and fan assisted
conguration.
e terminals, pipes and special pieces indicated in the following pages allow the ue gas to be exhausted outside the home,
through chimneys, piped systems or vertical and horizontal exhaust terminals.
e horizontal pipes can be installed with the rear, right side, le side and front outlet, making sure that the metal plates or
silicone buer wall sealing plates are correctly installed, fastening them appropriately until ush with the inside and outside wall.
3
4
5
2
1
INTAKE STUB PIPE KIT
Ø 80  CODE: 3.033759
Models:
VICTRIX PRO V2 35 EU
VICTRIX PRO V2 55 EU
VICTRIX PRO V2 60 EU
VICTRIX PRO V2 68 EU
VICTRIX PRO V2 80 EU
INTAKE STUB PIPE KIT
Ø 100  CODE: 3.033760
Models:
VICTRIX PRO V2 100 EU
VICTRIX PRO V2 120 EU
VICTRIX PRO V2 150 EU
3
4
5
1
2
INTAKE STUB PIPE KIT
Ø 160  CODE: 3.034565
Model:
VICTRIX PRO V2 180 EU
