Exploded view
Fig. 1
All work carried out on the pump has to be
performed in such a manner that risks for
personal injury are observed!
When handling liquids that may harm skin
use gloves and/or protective clothing.
When handling liquids which may involve
re hazards appropriate precautions to
avoid danger are to be taken.
In case of failure for a system with elevat-
ing pressure uid jets may cause injury
and/or damage.
Oil leakage may make the oor slippery
and cause personal injury.
Connecting and disconnecting of electric
cables must be done only by personnel
authorized to do such work.
Before any maintenance work, ensure
that the driver is deenergized and the
pump hydrauli cally isolated.
451
501
125
463
463A
537A 537
557A
557
537A
537
506
440
401
556
551
453
(608A)
(614)
(615)
(613)
(6120)
(608)
(605)
462A
462
122
351
113
1020
202
509
418
416
417
423
427
xVxx
xTxx
xTxx
