F.
B.
E.
• Remove the shaft
coupling.
• Remove the key 113.
Fig. 9 Fig. 10
Dismantling
ATTENTION
Use appropriate vessels to collect oil
spillage when removing and opening
the pump.
• Note the position of the shaft coupling.
• Release the stop screw.
A.
C.
Fig. 8
Fig. 7
Fig. 5
• Turn the electricity OFF.
• Close the valves.
• Remove the pump
from the system.
D.
• Remove the front cover 501 and power
rotor 1020.
Fig. 6
• Remove the
screws 451.
501
