Fig. 29
Pressure relief valve
ATTENTION
Spring tension.
• Release spring tension by turning set screw 6120
CCW as much as possible.
• Loosen and remove the screws 453.
• Separate the valve element from the rear cover
551.
• If necessary, replace the gasket 556 and the
O-ring 605.
• Reassemble the parts in reverse order. Be care-
ful to tighten the screws 453 crosswise.
• Readjust the valve pressure according to the
”Installation and Start-up Instruction for IMO Low
pressure pumps”.
6120
