IMO *G3D-250 - Page 15

15
Figures 2 through 10 Mechanical Types
Figure 2. Type 2 Single Mechanical Seal
Clamped or “J” Seat Type
Figure 3. Type 2 Single Spring Mechanical Seal
O-Ring Seat Type
Figure 4. Type 8-1 Multi Spring Mechanical Seal
Clamped or “J” Seat Type
Figure 5. Type 8-1 Multi Spring Mechanical Seal
O-Ring Seat Type
