IMO *G3D-250 - Assembly Drawing List and Mechanical Seal Types

5
Table 1
SERIES G3D TYPICAL PUMP ASSEMBLY DRAWINGS
MECHANICAL SEAL PACKING PUMPS
ROTOR SIZE
187 218 and 250 Vertical 218 312 187 218 and 250
FIGURE NO.
18 19 20 21 23 24
Table 2
SERIES G3D PUMP SEAL TYPES
ROTOR SIZES 187, 218, 250 and 312
PUMP
MODEL*
SEAL
FIG. NO.
PUMP
MODEL*
SEAL
FIG. NO.
PUMP
MODEL*
SEAL
FIG. NO.
PUMP
MODEL*
SEAL
FIG. NO.
PUMP
MODEL*
SEAL
FIG. NO.
G3DB
6 or 7
G3DJS
8
G3DYST
E
BG3DHST
4 or 5
GG3DX
10
G3DBC
6 or 7
G3DJST
8
AG3DB
6 or 7
BG3DHT
4 or 5
GG3DXBJ
10
G3DBCST
6 or 7
G3DKCX
No Seal
AG3DBC
6 or 7
CG3DB
6 or 7
GG3DY
10
G3DBCSX
6 or 7
G3DKHS
No Seal
AG3DBCS
6 or 7
DG3DB
6 or 7
GG3DYFC
10
G3DBH
6 or 7
G3DLCS
2 or 3
AG3DBCX
6 or 7
DG3DH
4 or 5
GG3DYJ
10
G3DBR
6 or 7
G3DNST
10
AG3DBS
6 or 7
EG3DBS
6 or 7
GG3DYJV
10
G3DBRS
6 or 7
G3DQCS
Flexibox
AG3DBST
6 or 7
EG3DBSP
6 or 7
GG3DYS
10
G3DBRST
6 or 7
G3DRS
(Special)
AG3DBTCS
6 or 7
EG3DNST
4 or 5
GG3DYSJ
10
G3DBS
6 or 7
G3DSCS
Sealol
AG3DBX
6 or 7
FG3DHXS
4 or 5
GG3DYSX
10
G3DBST
6 or 7
G3DSRJ
4 or 5
A3DESX
4 or 5
GG3DBS
6 or 7
GG3DYT
10
G3DBSU
6 or 7
G3DSS
10
AG3DH
4 or 5
GG3DBSX
6 or 7
GG3DYX
10
G3DC
4 or 5
G3DU
10
AG3DHC
4 or 5
GG3DHS
4 or 5
HG3DB
6 or 7
G3DCC
4 or 5
G3DV
6 or 7
AG3DHS
4 or 5
GG3DNJ
10
HG3DBS
6 or 7
G3DCCS
4 or 5
G3DVCS
6 or 7
AG3DHST
4 or 5
GG3DNT
10
KG3DH
4 or 5
G3DEST
4 or 5
G3DVCST
6 or 7
AG3DJST
8
GG3DNSJ
10
LAG3DHS
4 or 5
G3DET
4 or 5
G3DW
Packing
AG3DKHP
No Seal
GG3DNST
10
LAG3DKH
No Seal
G3DF
Packing
G3DXS
4 or 5
AG3DKHS
No Seal
GG3DNSTX
10
LAG3DNRST
10
G3DG
9
G3DY
10
AG3DKHX
No Seal
GG3DRS
13
LBG3DBRST
6 or 7
G3DH
4 or 5
G3DYCSB
10
AG3DNST
4 or 5
GG3DSJX
10
LBG3DBST
6 or 7
G3DHCS
4 or 5
G3DYCSBT
10
AG3DRS
13
GG3DUCST
10
G3DHH
4 or 5
G3DYCST
10
AG3DXSJ
10
GG3DUSJ
10
G3DHST
4 or 5
G3DYRST
10
AG3DV
6 or 7
GG3DUST
10
G3DHX
4 or 5
G3DYSC
10
BG3DBST
6 or 7
GG3DUSTX
10
* Pump model precedes rotor size.
