Table 6
LIST OF MATERIALS (FIGURES 23 AND 24)
ITEM KIT DESCRIPTION ITEM KIT PART DESCRIPTION
001 Case 022 XX Thrust Plate
002 XX Housing 023 Spacer (2)
003 Plug 024 Bolt (2)
004 Tube 025 Lockwasher (2)
005 X O-ring (2) 026 Inlet Head
006 X O-ring 027 Key
007 X O-ring 028 Elbow (2)
008 X Gasket 029 Nipple (2)
009 XX Inboard Cover 030 XX Check Valve
010 XX Capscrew (2) 031 Tubing
011 Bolt (8) 032 Tee
012 XX Power Rotor 033 Nameplate
014 X Balance Piston Housing 034 Drive Screw (3)
015 Spacer 035 Plug
016 X Packing 036 Elbow
017 Packing Gland 037 Spring Pin (2)
018 Gland Screw (2) 038 Nut (2)
019 Washer (2) 039 Nipple
020 XX Idler (2) 040 Nipple
021 XX
Idler Cups***
(X) Minor Repair Kit items
(XX) Major Repair Kit items. Items marked (X) also included in Major Repair Kit.
Quantities are one (1) except when noted in parentheses after part description.
*** Note: Some Idlers have a hydrostatic thrust design and do not need idler cups (21).
